10 Access Control Install Mistakes

Secura Key System White

1. NOT INSTALLING SURGE PROTECTION

We recommend surge protection on all data lines and reader cables, as well as for plugin power supplies at each panel. Remember that surge protectors need a good path to Earth Ground to work properly. While nothing can prevent damage from a direct lightning hit, surge protectors will prevent damage from nearby lightning strikes, which can disable your system.


2. POWERING DOOR STRIKES AND MAG LOCKS FROM THE SAME SUPPLY AS THE PANEL (or standalone unit)

Strikes and maglocks can send voltage spikes back through the power supply into an access control panel, causing circuit damage or data errors. Purchase separate power supplies for each door locking device.


3. NOT ORDERING SPARES

For every 10 doors in a system, we recommend having one control panel PCBA and two readers on hand, in case of a direct lightning hit or other catastrophic problem. This will get your system back online, without waiting for equipment to be ordered and shipped. This also reduces trips back to the shop for the installer.


4. USING THE WRONG CABLE

With Secura Key, you can use twisted pair cable such as CAT5 or CAT6 for RS-485 communications (from panel to panel or back to the PC). Wiegand communications (from reader to panel) require non-twisted cable, such as 6-cond shielded (the same as for RS-232 connections). System installation manuals will call out the correct cable for every application.


5. NO EXPERIENCE WITH DOOR HARDWARE

If you are experienced with electronics, software, alarm systems, CCTV, and other low voltage equipment, don’t assume that you can competently install an electric strike, mag lock or electrified lockset. You can make a mess of an expensive commercial door frame or door if you have no hardware installation experience. When in doubt, subcontract a locksmith to handle the door hardware.


6. NO EXPERIENCE WITH ELECTRONICS

If you are experienced with door hardware, etc, but not familiar with electronics, software, and low voltage equipment, don’t try to fake your way through the installation. When in doubt, subcontract an access control installer to handle the wiring, software installation and any network interfaces. If you can’t find an access control installer, home automation or alarm installers are generally familiar with similar types of equipment.


7. ORDERING WRONG READERS

If you are adding on to an existing system, you need to be 100% certain of the make, model and part number of the existing readers. Don’t send the manufacturer or distributor a picture of the reader because a lot of different readers use the same plastic housing. Go to the job site or get someone at the job site to find a screwdriver, remove the reader from the wall or mounting plate and read the ID label on the inside of the reader. Get all of the information, including firmware versions and output formats.


8. ORDERING WRONG CARDS

If you are adding cards to an existing system, knowing the data format, facility code and card ID Number range of the existing cards is critical. The technology (prox, contactless, Wiegand, magstripe, etc) and brand of the new cards must be identical or guaranteed compatible with the existing cards. The facility code of the new cards should match the existing ones. While some systems will allow you to mix different facility codes, the ID numbers of the new cards cannot duplicate any of the existing ID numbers, and should not exceed the upper limit of the system (many systems only accept cards up to 65535). If you make a mistake when ordering cards, most companies will not take custom encoded cards back, so you may get stuck with some very expensive cards.


9. NOT PRE-STAGING THE SYSTEM

Experienced installers never go to the job site without first trying to hook up and test the equipment at their shop or offices, especially if it is the first time they have installed a particular brand of equipment. Unpack all the equipment, place it on a large table, get out the manual, and connect all the components together using short cables. If you encounter difficulties, or if the products don’t work the way you anticipated, this gives you enough time to contact tech support and resolve the issues. This way, when you get to the job site, your customer will think you are the best in the business!


10. NOT BUYING SECURA KEY

With Secura Key, you get all the basic access control features, plus integrated badge printing and integrated video for 30-70% less than the competition. If you're not installing Secura Key, you're paying too much!
